Thumbnail Designs MS

Author: Flite Test STEM

Learning Strand: Ft Workbench

Level: All School Levels

Length: 1 hours. One period of Design Fundamentals based on exemplar schedule (Any given Monday)

Standards Addressed


INTERNATIONAL SOCIETY FOR TECHNOLOGY IN EDUCATION

ISTE STANDARDS FOR STUDENTS

  • Critical Thinking and Problem Solving
  • Technology Operations and Concepts
  • Creativity and Innovation
  • Communication and Collaboration

NATIONAL COUNCIL OF TEACHER MATHEMATICS STANDARDS MEASUREMENT

  • Understand both metric and customary systems of measurement.
  • Understand, select and use units of appropriate size and type to measure angles, perime Select and apply techniques and tools to accurately find length, area, volume and angle measurements to appropriate levels of precision.
  • Develop strategies to determine the surface area and volume of selected prisms, pyramids and cylinders.

NUMBERS AND OPERATIONS

  • Work flexibly with fractions, decimals and percents to solve problems.

GEOMETRY

  • Use two-dimensional representations of three-dimensional objects to visualize and solve problems such as those involving surface area and volume.

Objectives

STUDENTS WILL

  • Understand the use of thumbnail designs as a design strategy for possible solutions to a problem.
  • Understand the difference between the thumbnail designs compared to the final presented design to the solution.



Materials Needed

FT Thumbnail Design Template


TOOLS

Basic Standard or Metric Ruler

Activity

Step 1

MANUAL DESIGN

PRESENTING THE PROBLEM TO THE STUDENTS

TEACHER NOTE: The following lesson is designed to give the students practice with the use of thumbnails. First we need to present a problem that students will use to sketch some initial thumbnail designs. Introduce the concept of thumbnails as “quick ideas” as opposed to final workable designs, the difference being that thumbnail sketches are rough, small, unscaled drawings of a possible solution. They are not meant to be the workable design used for creating the solution.

Present the following problem;

“An R/C aircraft that can carry a half pound of candy”

Design Specifications:

  • Aircraft must have a wing span of 40” or less.
  • From nose to tail is 50” or less.
  • Must carry 2 sandwich bags full of Laffy Taffies.
  • A release mechanism must be present in order to drop candy!

Step 2

THUMBNAILS AND DESIGN PRESENTATION

TEACHER NOTE: Students are to practice thumbnail designs of their possible solutions. Teachers and advisors should work with students.

  • After presenting the problem, divide the students into teams of three to work together to bring an idea to the formal Design presentation.
  • All students within the team should have a FT Thumbnail Design Template (See Teacher Resources to download for printing).


  • Students should create thumbnail designs of the aircraft carrying the candy and of the mechanism that will release it.
  • After giving students time to draw ideas individually, have them share within their design team. After some time, make sure they agree on and circle one design.
  • Once all teams choose one design that they would like to try, have each group present their chosen solution to the class.
  • After this is complete, ask students what would be the next step. The answer should be to finalize a workable drawing with dimensions to then transfer onto materials for cutting.
